High Definition Fisheye Lens

● High resolution

● Various application meet your requirements

● Compact design with cost-effective performance

● Custom design

● Super wide-angle with FOV up to 180° for panoramic surveillance
● Sharp image quality for multi-mega pixels cameras
● Suitable for various image frame
● IR cut option

1/4" 0.89mm F2.0 Megapixel M4 mount 180degree IR-CUT Fisheye Lens forOV9281, suitable for 360 VR Camera, Drone UAV lens

MODEL 14089MPF-M4
IMAGE FORMAT 1/4" 3.888x2.448, 4.695mm (HxV, D)

IMAGE CIRCLE Φ2.448
FOCAL LENGTH(mm) 0.89
F.O.V. 180°(D)*180°(H)*180°(V)
RESOLUTION MP
F-THETA DISTORTION <-15.6%
APERTURE F2.0
MOUNT(mm) M4
IRIS Fixed
M.O.D.(mm) 0.1
B.F.L.(mm) 2.42mm (with 0.3mm filter)
T.T.L.(mm) 5.93mm (with 0.3mm filter)
R.I. >30%
Max. CRA 14.5°
DIMENSION(mm) Φ5.5x6.12 (without outside cover)
LENS COMPOMEMT 2-2(ASG)

Tips:
- ***MP: without IR-Cut filter
- ***MPF: with IR-Cut filter
- 650nm/850nm/940nm IR filter optional

- For more fisheye lenses, please feel free to contact us at sales01@megapixellenses.com; cctv.lens@ccom-tech.com
