High Definition Fisheye Lens
● High resolution
● Various applications meet your requirements

● Compact design with cost-effective performance
● Custom design

● Super wide-angle with FOV up to 195° for panoramic surveillance
● Sharp image quality for multi-mega pixels cameras
● Suitable for various image frame
● IR cut option

1/2.9" 2.2mm F2.3 1080P 4Megapixel M12*0.5 mount S-mount 195degrees super wide angle IR Fisheye Lens for vehicle cctv cameras & visual doorbell, 2.2mm 1080P 4MP fisheye lens for OV4689

MODEL 129022MPF
SENSOR 1/2.9", OV4689

IMAGE FORMAT(HxV, D) 5.38x3.04, 6.2

MAX IMAGE CIRCLE Φ6.2mm
FOCAL LENGTH(mm) 2.2
FOV(D*H*V) OV4689 195°*155°*81°
RESOLUTION 4MP
APERTURE 2.3
MOUNT(mm) M12x0.5
F-theta distortion -17%
Relative illumination: >70%
CRA: <15.9°
IRIS Fixed
B.F.L.(mm) 4.6 (in air)
T.T.L.(mm) 18.81 (in air)
M.O.D.: 0.1m
LENS DIMENSION Φ15*14.87mm

LENS CONSTRUCTION 6-5

Tips:
- ***MP: without IR-Cut filter
- ***MPF: with IR-Cut filter
- 650nm/850nm/940nm IR filter optional

- For more fisheye lenses, please feel free to contact us at sales01@megapixellenses.com; cctv.lens@ccom-tech.com

129022MPF + S2LM(DSP) OV4689 effect(Before distorion collection, not original image quality):

Effect on IMX226(compressed, not original image qulity):
