High Definition Fisheye Lens

● Mini fisheye lens suggested for 1/4", 1/3.2" 5MP image sensors(i.e. AR0542, MT9P111, OV5642)
● High resolution, more than 30% contrast at 200lp/mm at corner
● Mini size for wide range of applications including consumer electronics

● All glass elements and metal housing
● Even image quality between center and corner
● High relative illumination(≥75% at corner)
● IP66 grade waterproof for option

Applications
- Panoramic security
- Machine vision

- 3D mobile vision
- Automotive

- Consumer electronics

1/4" 1.27mm 5Megapixel M7*0.35 mount 185degrees super wide angle IR Fisheye Lens for 1/4" 1/3.2 5MP image sensor AR0542/MT9P111/OV5642/OV4689 etc.

MODEL 140127MP-M7
IMAGE FORMAT 1/4" (image circle diameter 2.8mm)
FOCAL LENGTH(mm) 1.27
FOV(D*H*V) 185°*185°*155°
RESOLUTION 5MP(30% at 250 lp/mm)
APERTURE 2.8
MOUNT(mm) M7x0.35 or M12x0.5
F-theta distortion -23.7%
Relative illumination: 76% at full field
CRA at corner: 8.9 deg.
Filter option(50% at 650nm+/-10nm)
IRIS Fixed
B.F.L.(mm) 3.95
LENS DIMENSION Φ12*13.32mm

Tips:
- ***MP: without IR-Cut filter
- ***MPF: with IR-Cut filter
- 650nm/850nm/940nm IR filter optional

- M12 mount version: http://www.megapixellenses.com/sale-8078109-1-4-1-27mm-5megapixel-m12x0-5-mount-185degrees-super-wide-angle-ir-fisheye-lens.html

- For more fisheye lenses, please feel free to contact us at sales01@megapixellenses.com; cctv.lens@ccom-tech.com

MTF data:
