    1/3" 1.05mm 10Megapixel S mount M12 202degree Fisheye Lens for IMX172 IMX214, Drone UAV 360VR lens

    Ask Lasest Price
    Model Number : 130105MP 130105MPF
    Delivery Time : 2-7 work days
    Supply Ability : Samples available
    Payment Terms : T/T, Western Union, Moneygram, Paypal
    Brand Name : CCOM LENS
    • Product Details
    • Company Profile

    1/3" 1.05mm 10Megapixel S mount M12 202degree Fisheye Lens for IMX172 IMX214, Drone UAV 360VR lens

    High Definition Fisheye Lens

    ● High resolution

    ● Various application meet your requirements

    ● Compact design with cost-effective performance

    ● Custom design

    ● Super wide-angle with FOV up to 202° for panoramic surveillance
    ● Sharp image quality for multi-mega pixels cameras
    ● Suitable for various image frame
    ● IR cut option


    1/3" 1.05mm 10Megapixel S mount M12*0.5 Mount 202degree IR Fisheye Lens, 1.05mm fisheye lens for IMX172/IMX214/OV10823, suitable for 360 VR Camera, Drone UAV lens, able to match 10MP sensors


    MODEL 130105MP
    IMAGE FORMAT 1/3" / Φ3.46mm(image circle)
    FOCAL LENGTH(mm) 1.05
    F.O.V. 202°(D)*202°(H)*202°(V)
    RESOLUTION 10MP
    F-THETA DISTORTION <-7.71%
    APERTURE F2.4
    MOUNT(mm) M12x0.5
    IRIS Fixed
    M.O.D.(mm) 0.1
    B.F.L.(mm) 3.2
    T.T.L.(mm) 24.5mm
    R.I. >70%
    Max. CRA 5.2°
    DIMENSION(mm) Φ26x21.9
    LENS COMPOMEMT 10-7


    Tips:
    - ***MP: without IR-Cut filter
    - ***MPF: with IR-Cut filter
    - 650nm/850nm/940nm IR filter optional

    - This 1.05mm fisheye lens can be used on 1/2.6" sensors: http://www.megapixellenses.com/sale-8078125-1-2-6-1-08mm-10megapixel-m12x0-5-mount-200degrees-fisheye-lens-for-ccd-cmos.html

    - For more fisheye lenses, please feel free to contact us at sales01@megapixellenses.com; cctv.lens@ccom-tech.com


    2pcs 130105MP fisheye lenses back to back on IMX214:

    1/3" 1.05mm 10Megapixel S mount M12 202degree Fisheye Lens for IMX172 IMX214, Drone UAV 360VR lens


    Effect on IMX172:

    1/3" 1.05mm 10Megapixel S mount M12 202degree Fisheye Lens for IMX172 IMX214, Drone UAV 360VR lens
