1/2.5" 1.56mm F2.0 5Megapixel M12x0.5 Mount 180degree panoramic camera Fisheye Lens, 1.56mm Mini Fisheye Lens for 180º 360º panoramic cameras

MODEL 1250156MP
IMAGE FORMAT 1/2.5"

MAX IMAGE CIRCLE Φ4.7mm
FOCAL LENGTH(mm) 1.56 ±3%
FOV 180°(D)*180°(H)*168°(V)
RESOLUTION 5MP
APERTURE 2.0

TV DISTORTION <-33%
MOUNT(mm) M12x0.5
IRIS Fixed
M.O.D.(m) 0.2
B.F.L.(mm) 4.31

M.B.F.(mm) 4.11

T.T.L.(mm) 20.80 ±0.2

LENS COMPOMEMT 6G
DIMENSION(mm) Φ20x16.4

Tips:
- ***MP: without IR-Cut filter
- ***MPF: with IR-Cut filter
- 650nm/850nm/940nm IR filter optional

- For more fisheye lenses, please feel free to contact us at sales01@megapixellenses.com; cctv.lens@ccom-tech.com

Effect on 1/2.5" sensor:

We are professional supplier of camera lenses and keeping providing innovative optical solutions and products to the market. We specialize in Megapixel Fisheye Lenses, Megapixel S-Mount(M12x0.5) Board Lenses, Megapixel M10/M9/M8/M7/M6/M5 Mount Lenses, CCTV Lenses/Medical Lenses, Pinhole Lenses, C Mount Lenses/ITS Lenses for Highway monitoring application, Vari-focal M12x0.5 Mount Lenses, Vari-Focal CS Mount Lenses, Megapixel Vari-Focal C/CS Mount Lenses, Fixed/Mono-Focal CS Mount Lenses, Megapixel Fixed/Mono-Focal CS Mount Lenses, etc.

We Keep providing new lens models for high-definition cameras in many applications, including Day& Night security, IP surveillance, Panoramic security, Video conferencing, Motion capture, Recognition, Sports, Machine Vision / FA, Automotive, Medical, etc.

We are committed to the R&D, design, manufacture and marketing of an extensive line of optical products. Any lens you need we could source, design and manufacture for you.

If you are interested in our optical products, please feel free to contact us. We are looking forward to our future cooperation and long-term partnership.
